SS220AS 数据手册

SS22AS THRU SS220AS

SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER

Reverse Voltage - 20 to 200 Volts Forward Current - 2.0 Amperes

FEATURES

The plastic package carries Underwriters Laboratory

SMAS

Flammability Classification 94V-0

For surface mounted applications

Cathode Band

Top View

Metal silicon junction,majority carrier conduction

Low power loss,high efficiency

Built-in strain relief,ideal for automated placement

0.110(2.80)

0.094(2.40)

0.059(1.50)

0.051(1.30)

High forward surge current capability

High temperature soldering guaranteed:

260 C/10 seconds at terminals

0.144(3.65)

0.128(3.25)

0.010(0.25)

0.004(0.10)

0.043(1.10)

0.039(1.00)

0.047(1.20)

0.028(0.70)

MECHANICAL DATA

Case: SMAS molded plastic body

Terminals: leads solderable per MIL-STD-750,

Method 2026

Polarity: Color band denotes cathode end

Mounting Position: Any

Weight:0.0011 ounce, 0.029 grams

0.189(4.80)

0.173(4.40)

Dimensions in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25 C ambient temperature unless otherwise specified.

Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.

SYMBOLS SS22ASSS23AS SS24AS SS25AS SS26AS

SS215AS SS220AS

SS28AS

SS210AS

UNITS

Maximum repetitive peak reverse voltage

Maximum RMS voltage

100

150

105

150

200

140

200

VRRM

VRMS

VDC

Maximum DC blocking voltage

Maximum average forward rectified current

at TL(see fig.1)

100

I(AV)

2.0

Peak forward surge current

IFSM

50.0

8.3ms single half sine-wave superimposed on

rated load

Maximum instantaneous forward voltage at 2.0A

0.95

2.0

0.55

220

0.70

0.85

0.5

10.0

0.1

Maximum DC reverse current

at rated DC blocking voltage

TA=25 C

TA=100 C

5.0

Typical junction capacitance (NOTE 1)

RθJA

RθJL

TJ,

180

95.0

16.0

Typical thermal resistance (NOTE 2)

C/W

Operating junction temperature range

Storage temperature range

-55 to +125

-55 to +150

TSTG

-55 to +150

Note:1.Measured at 1MHz and applied reverse voltage of 4.0V D.C.

2.P.C.B. mounted with 0.2x0.2”(5.0x5.0mm) copper pad areas

STAR SEA

DN:S04G10T01081907A0
