HMC568LC5
v05.1208
GaAs MMIC I/Q DOWNCONVERTER
9 - 12 GHz
Typical Applications
Features
The HMC568LC5 is ideal for:
Conversion Gain: 14 dB
Image Rejection: 33 dB
LO to RF Isolation: 55 dB
Noise Figure: 2 dB
• Point-to-Point and Point-to-Multi-Point Radio
• Military Radar, EW & ELINT
10
• Satellite Communications
Input IP3: -1 dBm
32 Lead 5x5mm SMT Package: 25mmꢀ
Functional Diagram
General Description
The HMC568LC5 is a compact GaAs MCM I/Q
downconverter in
a
leadless RoHS compliant
SMT package. This device provides a small signal
conversion gain of 14 dB with a noise figure of 2 dB and
33 dB of image rejection. The HMC568LC5 utilizes an
LNA followed by an image reject mixer which is driven
by an LO buffer amplifier. The image reject mixer
eliminates the need for a filter following the LNA, and
removes thermal noise at the image frequency. I and
Q mixer outputs are provided and an external 90°
hybrid is needed to select the required sideband. The
HMC568LC5 is a much smaller alternative to hybrid
style image reject mixer downconverter assemblies,
and it eliminates the need for wire bonding by allowing
the use of surface mount manufacturing techniques.
Electrical Specifications, TA = +25° C,
IF = 100 MHz, LO = 0 dBm, VD3 = 5V, VD1, VD2 = 3V*
Parameter
Min.
Typ.
Max.
Units
Frequency Range, RF
Frequency Range, LO
Frequency Range, IF
Conversion Gain (As IRM)
Noise Figure
9 - 12
GHz
GHz
GHz
dB
5.5 - 15.5
DC - 3.5
10
20
14
2.0
33
-7
dB
Image Rejection
dB
1 dB Compression (Input)
LO to RF Isolation
dBm
dB
40
20
55
38
-1
LO to IF Isolation
dB
IP3 (Input)
dBm
dB
Amplitude Balance
Phase Balance
1
5
Deg
mA
Total Supply Current
*Data taken as IRM with external IF Hybrid
160
208
For price, delivery, and to place orders, please contact Hittite Microwave Corporation:
20 Alpha Road, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373
Order On-line at www.hittite.com
10 - 2
