PD - 97096
iP2002PbF
Synchronous Buck
Multiphase Optimized BGA Power Block
Integrated Power Semiconductors, Drivers & Passives
Features:
• Output current 30A continuous with no derating up to
TPCB = 90°C and TCASE = 90°C
• Operating frequency up to 1MHz
• Dual sided heatsink capable
• Very small 11mm x 11mm x 2.6mm profile
• iP2001PbF footprint compatible
• Internal features minimize layout sensitivity *
• Optimized for very low power losses
iP2002PbF Power Block
Description
The iP2002PbF is a fully optimized solution for high current synchronous buck multiphase applications.
Board space and design time are greatly reduced because most of the components required for each
phase of a typical discrete-basedmultiphase circuitare integrated into a single 11mmx11mmx2.6mmBGA
power block. The only additional components required for a complete multiphase converter are a PWM IC, the
external inductors, and the input and output capacitors.
iPOWIR technology offers designers an innovative board space saving solution for applications
requiring high power densities. iPOWIR technology eases design for applications where component
integration offers benefits in performance and functionality. iPOWIR technology solutions are also optimized
internally for layout, heat transfer and component selection.
iP2002PbF Internal Block Diagram
V
IN
PRDY
ENABLE
MOSFET
Driver with
dead time
control
VSW
PWM
VDD
SGND
PGND
* All of the difficult PCB layout and bypassing issues have been addressed with the internal design of the iPOWIR Block. There are no
concerns about double pulsing, unwanted shutdown, or other malfunctions which often occur in switching power supplies. The iPOWIR
Block will function normally without any additional input power supply bypass capacitors. However, for reliable long term operation it is
recommended that at least four 10uF ceramic input decoupling capacitors are provided to the VIN pin of each power block. No additional
www.irf.com
1
5/16/06
