BR315F 数据手册

BR38F~BR320F

SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER

VOLTAGE

CURRENT

80-200Volt

3 Ampere

SMBF

Unit : inch(mm)

FEATURES

• Plastic package has Underwriters Laboratory Flammability

Classification 94V-O

• For surface mounted applications in order to optimize board space

• Ultra thin profile package for space constrained utilization

• Package suitable for automated handling

• Low power loss,high efficiency

• High surge capacity

• Lead free in compliance with EU RoHS2.0 (2011/65/EU & 2015/865/EU

directive)

• Green molding compound as per IEC61249 Std. . (Halogen Free)

MECHANICAL DATA

• Case: SMBF molded plastic

• Terminals: Solder plated, solderable per MIL-STD-750,Method 2026

• Approx. Weight: 0.0018 ounces, 0.05 grams

• Polarity: Color band denotes cathode end

• Marking: Part number

Cathode

Anode

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS (TA=25^oC unless otherwise noted)

PARAMETER

Recurrent Peak Reverse Voltage

SYMBOL

BR38F

BR39F

BR310F BR315F BR320F UNITS

V_RRM

100

150

105

150

200

140

200

RMS Voltage

V_RMS

DC B locking Voltage

Average Forward Current

V_R

I_F(AV)

I_FSM

V_F

Peak Forward Surge Current : 8. 3ms single half sine-wave

superimposed on rated load

Forward Voltage at 3A

0. 8

0.9

DC Reverse Current at Rated DC Blocking Voltage

Typical Junction Capacitance ( V_R=4V, f=1MHz)

I_R

0.05

^OC / W

^OC

C_J

120

100

Typical Thermal Resistance ,Junction to Lead (Note 1)

Junction to Ambient (Note 2)

R_θJL

R_θJA

135

Operating Junction Temperature and Storage Temperature Range

T_J,T_STG

-65 t o +150

NOTES :

1. Mounted on FR-4 PCB, single-sided copper, with 100cm copper pad area.

2. Mounted on FR-4 PCB, single-sided copper, mini pad.

March 9,2016-REV.02

PAGE . 1
