DCS7-16 数据手册

POWER TRANSFORMER

DCS7-16 (F) SERIES

1. CONFIGURATION & DIMENSIONS :

4.76(0.187)Quick Connect

Solder Lug Terminal

9.53

(0.375)

4.76(0.187)Dia. Mfg.

Holes

6.35

(0.250)

3.96

(0.156)

UNIT : mm (inch)

SIZE

gram

93.68

(3.688)

46.05

(1.813)

57.15

(2.250)

68.28

27.00

79.38

(3.125)

771.11

(2.688)

(1.063)

2. SCHEMATIC :

indicates polarity

3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) :

a. Primary Voltage

AC 115/230 V 50/60 Hz .

Less Than 80mA / 105mA .

b. No Load Primary Current

c. Secondary Voltage (±5%)

Pin 6-10 C.T. Pin 8

AC 18.50 V / 18.50 V .

3.50A .

d. Secondary Load Current

Less Than 620mA / 330mA .

16.00V / 16.00V .

e. Full Load Primary Current

f. Full Load Secondary Voltage (±5%)

Pin 6-10 C.T. Pin 8

g. DC Resistance

Pin 1-2

Primary-1 = 18.00 Ohm .

Primary-2 = 21.80 Ohm .

Secondary-1 = 0.130 Ohm .

Secondary-2 = 0.145 Ohm .

DC 500V 100Meg Ohm Of More .

AC 2500V 60Hz 1 Minutes .

Less Than 60 Deg C .

Pin 4-5

Pin 6-8

Pin 8-10

h. Insulation Resistance

i. Withstand Voltage (Hi-Pot)

j. Temperature Rise

k. Core Size

EI-66 x 26.00 m/m .

l. Turns & Wire Gauge

Primary-1

Primary-2

Secondary

Pin 1-2

585

Turns Diameter 0.29 m/m .

Pin 4-5

Pin 6-8-10

0-47-94 Turns Diameter 1.00 m/m .

NOTE : Specifications subject to change without notice. Please check our website for latest information.

25.02.2008

SUPERWORLD ELECTRONICS (S) PTE LTD

PG. 1
