8462 数据手册

10/100 Base-TX

Dual Port Transformer Modules

LAN

8460-8464

Designed to support two (2) RJ-45 connectors. These units are for use

with transceivers requiring 1:1 transmit and receive turns ratios.

•

Exceeds IEEE 802.3u and ANSI X3.263 standards including 350µH

OCL with 8mA bias

Modules can withstand a peak temperature profile of 235 °C.

MECHANICAL (All dimensions in inches)

ELECTRICAL SPECIFICATIONS @ 25˚C

Insertion

Common to Common

Rejection Ratio

0.1-60 MHz (dB TYP) Rejection (dB TYP)

Differential to

Common Mode

Return Loss

(dB MIN)

Crosstalk

(dB TYP)

Loss

(dB TYP)

0.1-100

MHz

-1.2

-0.5

Part

Number

2-30

MHz

-16

-21

MHz

-14

-17

MHz

-13

-14.5

60-80

MHz

-12

100

1-60

MHz

-37

60-200

MHz

-33

Transmit

Receive

MHz MHz MHz MHz

8460

8461

8462

8463

8464

-50

-65

-45

-55

-40

-45

-35

-40

-30

-45

-40

-30

-40

-30

-53

-40

-21

-12

-45

-35

-45

-35

NOTE: All models meet input/output breakdown (Hipot) of 1500 Vrms.

229 Colonnade Road, Nepean, Ontario, Canada K2E 7K3

Tel: (613) 226-1626 Fax: (613) 226-7124 www.filtran.com

An ISO 9001 Registered Company
