Datasheet > HBE472MBBCRUKR

HBE472MBBCRUKR

更新时间： 2025-10-10 21:22:27

品牌	Logo	应用领域
威世 - VISHAY		电容器
页数	文件大小	规格书
4页	75K
描述
CAPACITOR, CERAMIC

阅读下载

中文翻译

获取价格

技术参数
数据手册

如果您发现信息不准确，欢迎纠错

HBE472MBBCRUKR 技术参数

是否无铅：	不含铅	是否Rohs认证：	符合
生命周期：	Active	包装说明：	,
Reach Compliance Code：	unknown	ECCN代码：	EAR99
风险等级：	5.76	电容器类型：	CERAMIC CAPACITOR
介电材料：	CERAMIC	JESD-609代码：	e3
端子数量：	2	端子面层：	Matte Tin (Sn) - with Nickel (Ni) barrier
Base Number Matches：	1

HBE472MBBCRUKR 数据手册

HBU, HBZ, HBE, HBX Series

www.vishay.com

Vishay Draloric

Ceramic Singlelayer DC Disc Capacitors,

2 kV_DCGeneral Purpose

FEATURES

• High capacitance in small sizes

• Low losses

• Wide range of different leadstyles

• Material categorization:

For definitions of compliance please see

www.vishay.com/doc?99912

APPLICATIONS

• Lighting ballasts

• SMPS

DESIGN

The capacitors consist of ceramic disc both sides of which

are silver plated. Connection leads are made of tinned

copper having diameters of 0.6 mm or 0.8 mm.

QUICK REFERENCE DATA

DESCRIPTION

VALUE

The capacitors may be supplied with straight or kinked

leads having a lead spacing of 7.5 mm.

Ceramic Class

Coating is made of blue colored flame retardant epoxy resin

in accordance with UL 94 V-0.

Ceramic Dielectric

N750, Y5T, Y5U, Y5V

2000

Voltage (V_AC

)

Min. Capacitance (pF)

Max. Capacitance (pF)

Mounting

470

CAPACITANCE RANGE

10 pF to 22 nF

22 000

Radial

RATED VOLTAGE

2 kV_DC

MARKING

Marking indicates, capacitance, tolerance code, and rated

voltage.

DIELECTRIC STRENGTH

3000 V_DC, 2 s

Component test

OPERATING TEMPERATURE RANGE

- 40 °C to + 85 °C

INSULATION RESISTANCE AT 500 V_DC

10 000 M (60 s)

TEMPERATURE CHARACTERISTICS

TOLERANCE ON CAPACITANCE

10 %, 20 %, - 20 %/+ 50 %

Class 1

N750 (U2J)

Class 2

Y5T, Y5U, Y5V

DISSIPATION FACTOR

SECTIONAL SPECIFICATIONS

Climatic category (according to EN 60068-1):

40/085/21

Class 1:

100 pF

-4







------------------

C < 30 pF:

+ 0.7 x 10 max. 1 MHz



C  30 pF: Max. 0.1 % (1 MHz)

Class 2: Max. 2.5 % (1 kHz)

Revision: 15-Feb-13

Document Number: 22152

For technical questions, contact: slcap@vishay.com

THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT

ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000

12 3 4
